Key specifications

34465A

34470A

Digits of resolution

6½

7½

Basic DCV accuracy

30 ppm

16 ppm

Max reading rate

5,000 rdgs/s std 50,000 rdgs/s opt

5,000 rdgs/s std 50,000 rdgs/s opt

Memory

50,000 rdgs std 2 million rdgs opt

50,000 rdgs std 2 million rdgs opt

Measurements

34465A

34470A

DCV, ACV

100 mV to 1,000 V

100 mV to 1,000 V

DCI

1 μA to 10 A

1 μA to 10 A

ACI

100 μA to 10 A

100 μA to 10 A

2- and 4-wire resistance

100 Ω to 1,000 MΩ

100 Ω to 1,000 MΩ

Continuity, diode

Y, 5 V

Y, 5 V

Frequency, period

3 Hz to 300 kHz

3 Hz to 300 kHz

Temperature

RTD/PT100, thermistor, thermocouples

RTD/PT100, thermistor, thermocouples

Capacitance

1.0 nF to 100.0 μF

1.0 nF to 100.0 μF

Dual line display

Yes

Yes

Display

Color, graphical

Color, graphical

Statistical graphics

Histogram, bar chart, trend chart

Histogram, bar chart, trend chart

Rear input terminals

Yes

Yes

IO Interface

34465A

34470A

USB

Yes

Yes

LAN/LXI Core

Yes

Yes

GPIB

Optional

Optional
