PNA-X

Models

Frequency

Dynamic range at 3 G/20 G at 10 Hz IFBW

Max power at

3 G/20 G (dBm)

Best trace noise at

10 kHz IFBW Mag (dBrms)

/Phase (degrms)

Best speed at

201 point 1sweep,

correction off

System

(dB)

Directreceiver

access (dB)

Noise floor

(dBm/Hz)

N5249B

10 MHz to 8.5 GHz

124?128/

124?129

136?140/

133?141

-114/-114

+8?13/

+5?10

0.0063/0.047

5 ms

(600 kHz IFBW)

N5241B

10 MHz to 13.5 GHz

124?128/

124?129

136?140/

133?141

-114/-114

+8-13/

+5-10

0.0063/0.047

5 ms

(600 kHz IFBW)

N5242B

10 MHz to 26.5 GHz

N5244B

10 MHz to 43.5 GHz

118?123/ 121?125

136?140/

133?141

-110/-111

+8-13/

+10-14

0.0063/0.094

6 ms

(600 kHz IFBW)

N5245B

10 MHz to 50 GHz

N5247B

10 MHz to 67 GHz

124?130/

125?130

136?142/

136?140

-115/-118

+9?15/

+7?12

0.0063/0.063

9.7 ms

(600 kHz IFBW)

PNA

N5221B

10 MHz to 13.5 GHz

127/

124?127

139/

136?139

-114/-114

+13/

+10?13

0.0063/0.047

5.6 ms

(600 kHz IFBW)

N5222B

10 MHz to 26.5 GHz

N5224B

10 MHz to 43.5 GHz

125?127/

124?127

137?139/

136?139

-114/-114

+11?13/

+10?13

0.0095/0.063

4.7 ms

(600 kHz IFBW)

N5225B

10 MHz to 50 GHz

N5227B

10 MHz to 67 GHz

127/

124?127

138/

135?138

-114/-116

+9?13/

+8?11

0.0063/0.063

6.3 ms

(600 kHz IFBW)

PNA-L

N5239B

300 kHz to 8.5 GHz

131?133/

111?114

144/124

-120/-106

+11?13/

+5?8

0.012/0.19

5.75 ms

(600 kHz IFBW)

N5231B

300 kHz to 13.5 GHz

(N5231A Option 2xx)

N5232B

300 kHz to 20 GHz

(N5232A Option 2xx)

N5231B

300 kHz to 13.5 GHz

(N5231A Option 4xx)

128/

101?105

141/114

-120/-107

+8/

-6 -2

0.0063/0.063

5.75 ms

(600 kHz IFBW)

N5232B

300 kHz to 20 GHz

(N5232A Option 4xx)

N5234B

10 MHz to 43.5 GHz

110/100

128/117

-110/-100

0/0

0.019/0.19

6 ms

(600 kHz IFBW)

N5235B

10 MHz to 50 GHz
